4 Way Manual Phase Selector Distribution Board (Horizontal) | 63A / 100A | Copper Busbar | IP42
4 Way Manual Phase Selector Distribution Board (Horizontal) | 63A / 100A | Copper Busbar | IP42
The 4-Way Manual Phase Selector Horizontal Distribution Board provides a practical and reliable solution for maintaining power continuity in areas prone to phase imbalance or phase failure. Designed for 415 V AC, 50 Hz, 3 Phase + Neutral systems, it enables users to manually select the desired phase from R, Y, or B using three rotary selector switches, ensuring uninterrupted supply to critical loads. The distribution board features a robust tin-plated copper busbar, delivering excellent current-carrying capacity and long service life. It is available in 63 A and 100 A current ratings, making it suitable for a wide range of residential, commercial, and light industrial installations. An additional neutral link is provided to ensure safe, stable, and reliable operation during phase changeover. Engineered with a 5 kA short-circuit withstand capacity for 100 ms, the board offers enhanced protection against electrical faults. The powder-coated CRCA steel enclosure with IP42 degree of protection ensures durability and safety for indoor environments. Its horizontal configuration allows for easy access, clear wiring layout, and convenient operation.
The board supports both surface and flush mounting, offering flexibility during installation. Designed to operate reliably within an ambient temperature range of 0°C to 50°C and relative humidity up to 100%, it is suitable for diverse operating conditions. Fully compliant with IS 13032, IS 8623, and IEC/BSEN 60439-3 standards, the 4-Way Manual Phase Selector Distribution Board is backed by a 7-year standard warranty, making it a dependable choice for safe and continuous power distribution.
Description
The 4-Way Manual Phase Selector Horizontal Distribution Board provides a practical and reliable solution for maintaining power continuity in areas prone to phase imbalance or phase failure. Designed for 415 V AC, 50 Hz, 3 Phase + Neutral systems, it enables users to manually select the desired phase from R, Y, or B using three rotary selector switches, ensuring uninterrupted supply to critical loads. The distribution board features a robust tin-plated copper busbar, delivering excellent current-carrying capacity and long service life. It is available in 63 A and 100 A current ratings, making it suitable for a wide range of residential, commercial, and light industrial installations. An additional neutral link is provided to ensure safe, stable, and reliable operation during phase changeover. Engineered with a 5 kA short-circuit withstand capacity for 100 ms, the board offers enhanced protection against electrical faults. The powder-coated CRCA steel enclosure with IP42 degree of protection ensures durability and safety for indoor environments. Its horizontal configuration allows for easy access, clear wiring layout, and convenient operation.
The board supports both surface and flush mounting, offering flexibility during installation. Designed to operate reliably within an ambient temperature range of 0°C to 50°C and relative humidity up to 100%, it is suitable for diverse operating conditions. Fully compliant with IS 13032, IS 8623, and IEC/BSEN 60439-3 standards, the 4-Way Manual Phase Selector Distribution Board is backed by a 7-year standard warranty, making it a dependable choice for safe and continuous power distribution.
